EvoDECO Adhesive
Top quality labels and flexible configuration
Water
Beer
Food
Home & Personal Care
The EvoDECO Adhesive labeller has been designed to apply labels at industry-leading speeds of up to 66,000 bph while increasing efficiency. It can be equipped with six different carousel sizes and up to five labelling stations, for 36 possible configurations.
Optimised to suit the needs of beer, water, food, home and personal care producers, the solution is able to apply plastic or paper Pressure Sensitive Labels (PSL), even ultra-thin ones, with no compromises on quality performance even at high/very high speeds. For greater versatility and zero downtime, it can be configured with either two simultaneously engaged reels or according to a master-slave non-stop labelling system, applying one label.
|
Max Speed
|
Number of different labels/modules
| Bottle diameter (mm) |
Carousel diameter
|
Heads
|
Pitch
| |
|---|---|---|---|---|---|---|
| Min | Max | |||||
| 28,000 | 1 | 50 | 100 | 720 | 20 | 113 |
| 42,000 | 2 | 50 | 100 | 1080 | 30 | 113 |
| 50,000 | 2 | 50 | 100 | 1440 | 40 | 113 |
| 66,000 | 3 | 50 | 100 | 1800 | 50 | 113 |
| 66,000* | 3 (with vision system) | 50 | 110 | 2160 | 54 | 125 |
*Master-slave configuration
| Label length (mm) | Label height (mm) |
Label materials
|
Label thickness
| ||
|---|---|---|---|---|---|
| Min | Max | Min | Max | ||
| 20 | 150 | 20 | 220 |
PET, Paper |
Web liner: 20 - 50 µm Label: 50 - 90 µm |
The advanced unwinding, feeding and peeling control, through highly efficient servomotors, enables greater stability and precision in the labelling process:
The EvoDECO Adhesive labeller is designed to answer ever shifting market demands via unprecedented flexibility:
As production downtime is not an option, the EvoDECO Adhesive labeller increases efficiency and the quality of label application:
Always by your side on every step of the way to build, maintain and improve your line performance
