MACHINE FEATURES |
||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Max Mechanical Output (bph) | 240 | |||||||||
| Machine Dimensions L x W x H (mtr) | 4.5x3.3x2.7 | |||||||||
| Dimensions with Performa Feeder L x W x H (mtr) | NA | |||||||||
| Number of Heating Modules | 5 | |||||||||
| Number of Heaters per Module | 12 x 1.5 kw | |||||||||
| PC Industrial Processor | Intel E620T | |||||||||
| PC Screen | Touch Screen | |||||||||
BOTTLE SPECIFICATIONS |
||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Max. Bottle Diameter (mm) | 300 | |||||||||
| Max. Bottle Volume (Liters) | 20 | |||||||||
| Max. Bottle Height (mm) | 500 | |||||||||
| Max. Perform neck Dimension (mm) | 80 | |||||||||
| Max. Perform Height incl. neck (mm) | 420 | |||||||||
PERFORMANCE OEE |
||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Mechanical Efficiency (mm) | 95% | |||||||||
| Mold Changeover Time (in minutes for 2 technicians) | 60 | |||||||||
ENERGY |
||||
| AIR | Output (Lit. x bph) |
Low Pressure Air for System @ 8 bar (cfm) | Low Pressure Air @ 8 bar with Air Recovery (cfm) | High Pressure Air for Blowing @ 40 bar (cfm) |
| 20.0 x 240 10.0 x 350 5.0 x 550 |
NA | 0 | 166 160 120 |
|
| INSTALLED ELECTRICAL POWER 415V AC 50Hz ± 5% |
96 kW (Estimated consumption) 55-60% |
|||
| WATER (For Over Shields + Mold Cooling @8-12°C & 4 bar pressure) | 80 Lpm | |||
