MACHINE FEATURES |
||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Max Mechanical Output (bph) | 6200 | |||||||||
| Machine Dimensions L x W x H (mtr) | 3.8x3.3x1.8 | |||||||||
| Dimensions with Performa Feeder L x W x H (mtr) | 6.6x3.9x3.0 | |||||||||
| Number of Heating Modules | 3 | |||||||||
| Number of Heaters per Module | 10 x 1.5 kw | |||||||||
| PC Industrial Processor | Intel E620T | |||||||||
| PC Screen | Touch Screen | |||||||||
BOTTLE SPECIFICATIONS |
||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Max. Bottle Diameter (mm) | 110 | |||||||||
| Max. Bottle Volume (Liters) | 2 | |||||||||
| Max. Bottle Height (mm) | 360 | |||||||||
| Max. Perform neck Dimension (mm) | Upto 38 | |||||||||
| Max. Perform Height incl. neck (mm) | 160 | |||||||||
PERFORMANCE OEE |
||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Mechanical Efficiency (mm) | 95% | |||||||||
| Mold Changeover Time (in minutes for 2 technicians) | 45 | |||||||||
ENERGY |
||||
| AIR | Output (Lit. x bph) |
Low Pressure Air for System @ 8 bar (cfm) | Low Pressure Air @ 8 bar with Air Recovery (cfm) | High Pressure Air for Blowing @ 40 bar (cfm) |
| 0.2 x 6200 0.5 x 6200 1.0 x 6200 2.0 x 5800 |
75 | 20 10 0 0 |
135 185 265 405 |
|
| INSTALLED ELECTRICAL POWER 415V AC 50Hz ± 5% |
67 kW (Estimated consumption) 55-60% |
|||
| WATER (For Over Shields + Mold Cooling @8-12°C & 4 bar pressure) | 80 Lpm | |||
