EvoDECO Cold Glue
Hygienically designed for consistent uptime
Beer
Food
Home & Personal Care
Sidel's EvoDECO Cold Glue labeller is available in six carousel sizes and can feature up to five labelling stations, making it easy to configure according to bottle size, output need and product type.
Capable to generate outputs of up to 81,000 containers per hour, the labelling solution handles partial pre-cut paper labels, as such it is particularly suitable for the beer, food, home and personal care markets.
|
Max Speed
|
Number of different labels/modules
| Bottle diameter (mm) |
Carousel diameter
|
Heads
|
Pitch
| |
|---|---|---|---|---|---|---|
| Min | Max | |||||
| 24,000 | 2 | 50 | 128 | 1080 | 18 | 188 |
| 48,000 | 2 | 50 | 118 | 1440 | 36 | 125 |
| 60,000 | 3 | 50 | 118 | 1800 | 45 | 125 |
| 81,000 | 3 | 50 | 100 | 2160 | 60 | 113 |
| Station Model | Label lenght (mm) | Label height (mm) | Label materials | ||
|---|---|---|---|---|---|
| Number of pallets-grippers | Min | Max | Min | Max | |
| 5 - 5 | 20 | 195 | 20 | 200 | Paper Aluminium |
| 7 - 7 | 20 | 150 | 20 | 200 | |
| 8 - 8 | 20 | 130 | 20 | 120 | |
| 8 - 9 | 20 | 110 | 20 | 120 | |
The EvoDECO Cold Glue labeller ensures utmost hygiene:
The EvoDECO Cold Glue labeller maximises uptime and flexibility thanks to:
The Sidel EvoDECO Cold Glue labeller includes optimised glue and resource management:
Always by your side on every step of the way to build, maintain and improve your line performance
